This Chlorine Sensor 0-20 mg/L is a wide-range industrial probe for free chlorine monitoring. It applies membrane-free amperometric technology, requiring no membranes or chemical reagents. Built-in automatic temperature and pH compensation to guarantee accurate readings amid changing water quality.
Standard RS485 Modbus-RTU digital output for seamless connection with controllers and PLC. IP68 submersible rating, 3/4" NPT thread for quick installation. Low maintenance, stable performance for 24/7 continuous operation in water disinfection systems.
MTW-ACC100 Chlorine Sensor 0-20 mg/L features a standard measuring range of 0 to 20mg/L, suitable for most conventional chlorine monitoring scenarios. It adopts reliable electrochemical sensing principle, delivering quick response, high precision and stable measurement performance.
Built-in temperature compensation function effectively corrects data deviation caused by fluctuating water temperature. Equipped with standard RS485 MODBUS-RTU digital output, it is easy to connect with controllers, PLC and remote monitoring systems.
The sensor is fitted with anti-fouling diaphragm and IP68 fully sealed structure, which resists dirt and corrosion. It supports long-term submerged installation and minimizes routine maintenance work.
It is widely used in tap water plants, swimming pools, reclaimed water systems, industrial disinfection water and municipal water pipeline monitoring.
Product Features
- Stable zero-point performance
- Ensures accurate and reliable measurements
- Requires compatible flow equipment for use
- Simple structure, easy to clean
- Membrane-free design, no need for electrolyte or consumables
- Suitable for residual chlorine, chlorine dioxide, and ozone in water
- Can be compared with DPD measurement method
SEO Keywords
Technical Parameters
|
Measurement Parameter |
Residual Chlorine/Dissolved Ozone |
 |
|
Dimensions |
13 × 120 mm |
|
|
Material |
Stainless steel |
|
|
Electrode Material |
Platinum |
|
|
Range |
0–2.000 mg/L, 0–20.00 mg/L |
|
|
Accuracy |
±5% |
|
|
Temperature Range |
0–50°C |
|
|
Temperature Sensor |
PT1000 |
|
|
Flow Rate Requirement |
20–40 L/h |
|
|
Cable Length |
5 m (open-ended) |
Product Application
Tap water treatment, swimming pool & spa, wastewater disinfection, industrial process water, secondary water supply, food & beverage water systems.
